Pure PTFE With Kevlar Fiber Corner Braided Packing

Pure PTFE With Kevlar Fiber Corner Braided Packing Corner ptfe kevlar packing STYLE 6500 PTFE is pure PTFE yarn braided packing incorporated with pure 100% Dupont's Kevlar yarn throughout the four corners. This structure enhances the lubricating ability of Aramid and reinforced the strength...

Product Details


Pure PTFE With Kevlar Fiber Corner Braided Packing


Corner ptfe kevlar packing STYLE 6500 PTFE is pure PTFE yarn braided packing incorporated with pure 100% Dupont's Kevlar yarn throughout the four corners. This structure enhances the lubricating ability of Aramid and reinforced the strength of the pure PTFE packing. Good silding properties and thermal conductivity.

Every fiber is impregnated with PTFE emulsion. This system of impregnation assures even distribution of the PTFE. The fibers are saturated and sealed with PTFE particles, protecting the fibers from chemical action. To assure good break-in characteristics, a special high temperature synthetic lubricant is added.

Application:

1.Corner ptfe kevlar packing STYLE 6500PTFE can be used in piston pumps, valves, pulp, paper, waste water treatment, petrochemical, and other general industrial applications.

2.Corner ptfe kevlar packing STYLE 6500PTFE is suitable for oils, solvents, diluted acids and alkalis. Abrasive media like sand, slurry, sewage, brine and etc.

Advantages:

1.Elastic and flexible

2.Good silding properities and thermal conductivity

3.High temperature resistance

Not suitable for: Concentrated acids and lye, alkali metals, fluorine and fluorine compounds at high temperature.

Application Data:




Pressure: bar

25

500

250

Speed: m/s

25

2

PH Range

2-12

Temp.℃

-100 to +260

Density: (g/cm³)

1.40-1.45

Size

1/4"-2"

6mm-50mm

Package(Per Spool):

Regular:3m, 8m, 1kg, 1 pound, 2.5kg, 2.5 pound, 5kg, 5 pound,10kg, 10 pound.

Other packages are available on request










1. What is your MOQ?

MOQ may vary by customer's special requirement; we try our best to meet your business requirement.

2. What's your payment terms?

We normally do T/T, and we can also offer western union account for transfer money. And more flexible payment terms, welcome to have a discuss.

3. Can you provide samples?

Yes, we can offer samples, and some samples are free

4. Can you delivery by express?

Yes, we can delivery by any express.

5. When will the sample be ready?

Normally, the sample can be ready in 3 days.

Tenglong is one of the leading China Kevlar Fiber Packing manufacturers and also a famous such supplier, welcome to wholesale cheap and good quality pure ptfe with kevlar fiber corner braided packing from our factory.
