Fireproof Seal Silica Board Heat Insulation Ceramic Fiber Board

Ceramic Fiber Board 1.Tenglong ceramic fiber board is made from refractory fiber pulp with minimum amount of organic bond agent or abio-bond. 2.If smoke is generated when ceramic fiber board is initially heated, it does not affect the ceramic fiber board's high temperature insulation...

Chat Now
Product Details

Fireproof Seal Silica Board Heat Insulation Ceramic Fiber Board

  Ceramic fiber board is a vacuum formed product that resists higher gas velocities than ceramic fiber blanket.
Fire Resistant Fiber Board by adding a small amount of high-purity alumina silicate fiber binders, which is made through automation control and continuous production process, with a host of features such as precise size, good flatness, high strength, lightweight,excellent thermal shock resistance and anti-stripping, which can be widely used for insulation in the linings around and at the bottom of kilns, as well as ceramic kilns fire position, craft glass mold and other positions.


  Resists abrasion

  Resists most acids and alkalis

Applications :

  Transfer of non-ferrous metals.

  Shuttle kiln with high gas velocity

  Expansion joiot boards.

Barrier against flame.


  Low heat storage

  Low thermal conductivity

  Excellent abrasive resistance

  Excellent thermal shock resistance

  Excellent chemical stability

  Even density and thickness


  600*400*20-50;900*600*20-50,other made according to customers's requirement.




Fire Resistant Fiber Board


ceramic fiber


The thinnest board size:3-10mm(Density:320-350kg/m3)

The large board size :10-80mm(Density:280-400kg/m3)

Regular size:1200X1000X(10-80), 1200X600X(10-80)

1000X1000X(10-80), 900X600X10,600X300X10mm

Working temperatures

1050Ordinary Ceramic Fiber Board--950C

1260Standard Ceramic Fiber Board---1050C

1260High-purity Ceramic Fiber Board- --1100C

1400High Aluminum Ceramic Fiber Board---1200C

1450Zirconia Ceramic Fiber Board---1350C


Non-brittle material, good elasticity

Good sound insulation;

Accurate sizes and good flatness

Kiln construction: Hot surface refractories, heavy refractory back linings, expansion joints.

Light industry: Industrial and household boiler combustion chamber lining;

Petrochemical industry: as high-temperature furnace hot surface lining material;

Craft glass: As craft glass or other deep-processed and molded products mold;


plastic bag inside, carton or woven bag outside,


Tenglong is one of the leading China Ceramic Fiber Products manufacturers and also a famous such supplier, welcome to wholesale cheap and good quality fireproof seal silica board heat insulation ceramic fiber board from our factory.
Hot Tags: fireproof seal silica board heat insulation ceramic fiber board, China, manufacturers, supplier, factory, wholesale
