Flexible Graphite Paper Adhesive Backed
SUNPASS Flexible Graphite Paper Adhesive Backed is made from exfoliated graphite flake and produced through an extensicve calendaring process to give a thin flexible paper with no binder or resins. Because of the excellent properties such as thermal stability, high and low temperature resistance, impermeability and corrosion resistanbce, etc. The product is widely used in fields of industrial sealing, heating elements for high temperature applications and insulation shields.
Flexible Graphite Paper Adhesive Backed Features
| Heat and flame resistant | ||||
| Low creep relaxation and no aging | ||||
| Flexible and conformable nature | ||||
| Chemical resistant, compatible with most chemicals | ||||
| Electrical conductive | ||||
Flexible Graphite Paper Adhesive Backed Specification
| Property | Description | Data | |||
| Carbon Content(Purity) | - | 99% | |||
| Thickness | English | 0-0.135in | |||
| Metric | ≤±HX7%, 0-4.5mm | ||||
| Density | English | 43-81lb/ft3 | |||
| Metric | ≤±0.07g/cm³, 0.7-1.3g/cm3 | ||||
| Material | Nature Graphite | - | |||
| Working Temperature | English | -40 to +752℉ | |||
| Metric | -40 to +400℃ | ||||
| Tensile Strength | - | ≥4.0 MPa | |||
| Thermal Conductivity | Through Thickness | 36 BTU.in/ft2.h.F (5 W/m.K) | |||
| Parallel to Surface | 960 BTU.in/ft2.h.F (140 W/m.K) | ||||
| pH Range | 1-14 | - | |||
| Compressibility | 35%-55% | ||||
| Recovery | ≥9% | ||||
| Ash Content | ≤1.0% | ||||
| TAG(450℃) | ≤1.0% | ||||
| Total Sulphur Content | ≤500ppm | ||||
| Max Temp. Oxyd Atmosphere | 650° C | ||||
| Max Temp. Non oxyd Atmosphere | 3000℃ | ||||
| Chloride content | < 25 ppm | ||||
| Inhibitor (against oxidation) | with anorganic | ||||
| Iron content | < 1800 ppm | ||||
| Leachable Sulphur | < 200ppm | ||||
