NON ASBESTOS SHEET
NON ASBESTOS SHEET Material:
Non asbestos sheet made of special non-asbestos heat-resisting Fibre, heat-resisting packing material and nature rubber compound heating and compression molding it.
Uses: Substitution of corresponding models of asbestos rubber sheet ,Used for the equipment in water,steam,etc.and used as sealing material in the joints of pipeline
NON ASBESTOS SHEET Sizes:
4100 x 1500 x (0.5 – 6.0)mm, 2000 x 1500 x (0.5 – 6.0)mm,
1500 x 1360 x (0.5 – 6.0)mm, 3810 x 1270 x (0.5 – 6.0)mm
1270 x 1270 x (0.5 – 6.0)mm, 1500 x 1500 x (0.5 – 6.0)mm
The other size is optional or according to the requirements of customers.
Packing: in wooden pallet of about 1000 kgs, 2000kgs net each.
NON ASBESTOS SHEET Technical Datas:
| Item | NXB200 | NXB300 | NXB350 | NNY150 | NNY250 | NNY300 | NNY350 |
| Temperature C | 200 | 300 | 350 | 150 | 250 | 300 | 350 |
| Tensile strength MPa≥ | 5 | 7 | 11 | 8 | 10 | 12 | 15 |
| Aging Coefficient ≥ | 0.9 | ||||||
| Density g/cm³ | 1.9-2.0 | ||||||
| Compressibility % | 12 ± 7 | ||||||
| Rebound degree | 35 | 40 | 45 | 40 | 45 | 50 | 50 |
| Pliability | No Crack | ||||||
| Stress-relaxation≤ | 45 | 45 | 45 | 40 | 40 | 30 | 30 |
| Oil sealing With the temperature of 15℃ to 30℃,75﹟aviation gasoline for 30 min | 10 MPa pressure for 30 min No leaking | ||||||
| Tensile strength-reducing % | 40 | 30 | 25 | 25 | |||
| Thickness-increasing %≤ | 5to20 | 5to20 | 5to18 | 5to18 | |||
| Appearance change | No bubble | ||||||
With the temperature of 15 to 30℃, dipped in No.75 aviation oil for 5h, then taken out and laid for 5 min.
| Tensile strength MPa ≥ | 5 | 6 | 8 | 10 | ||
| Thickness | 5to25 | 5to25 | 5to20 | 5to20 | |||
| Pliability | No Crack | ||||||
