Expanded Graphite Sheet Description:
"Grafoil is Selected from the high purity natural flake graphite.
Expanded graphite sheets are made through the advanced chemical treatment and mechanical procedure without
fibers, binders or other additives.
Expanded graphite sheet offer excellent sealing capabilities under extreme conditions with a longer life and less
maintenance.Nuclear Style grade:440N "
Expanded Graphite Sheet Application:
"Expanded graphite sheets made for packing rings and various kinds of gaskets.
Cut into strip for filler of spiral wound gasket - Style TA440
Expanded graphite sheets used widely in chemical, automotive and pump, valve industries. As a superior replacement
for asbestos, new more applications are Being identified daily."
Expanded Graphite Sheet Temperature:
"-240~500°C under oxidizing environment
-240~3500°C under non-oxidizing environment"
Expanded Graphite Sheet Temperature:
0-14
| Expanded Graphite Sheet Parameter: | ||
| Item | Nuclear grade | Industrial grade |
| Tolerance of Density g/cm3 | ±0.05 | ±0.06 |
| Carbon Content ≥% | 99.5 | 98/99 |
| Tensile strength ≥Mpa | 5 | 4 |
| Compressibility ≥% | 35-55 | 30 |
| Recovery ≥% | 9 | 15 |
| Sulphur Content ≤% | 200 | 1200 |
| Chlorine Content ≤% | 50 | 50 |
| Stress relaxation rate % | 10 | 10 |
| Lgnition loss ≤% | 1 | 2 |
| DIMENSIONS: | ||
| Item | Sheets | Rolls |
| Density g/cm3 | 1 | 1 |
| Length | 1000, 1500mm | 30~100m |
| Width mm | 5~1000, 1500 | 3~1000~1500 |
| Thickness mm | 0.5~3 | 0.2~1.1 |
Special density, thickness, shape or grade available on request.
![N`MYWZ]LSCZ6CSP{QY$(Y4V](/Content/uploads/202335190/2023120810281161f7dbdbe0144f458b8d7f5228c61579.jpg "product-776-764")
1. What is your MOQ?
MOQ may vary by customer's special requirement; we try our best to meet your business requirement.
2. What's your payment terms?
We normally do T/T, and we can also offer western union account for transfer money. And more flexible payment terms, welcome to have a discuss.
3. Can you provide samples?
Yes, we can offer samples, and some samples are free
4. Can you delivery by express?
Yes, we can delivery by any express.
5. When will the sample be ready?
Normally, the sample can be ready in 3 days.
上方是模板内容,下方是编辑器原内容,编辑好请删除原内容.
Graphite Tanged Sheet
SUNPASS Tanged Graphite Sheet is a homogeneous material that contains no adhesives or binders. Even after long service periods, this material displays no notable change in its properties compared with other sealing materials. Inhibitors can be added to enhance oxidation and corrosion resistance properties of the flexible graphite if required. The two sides of the Tanged Graphite Sheet are pure expanded graphite plates with a metal core thickness of 0.1 mm and a stainless steel material of SS316L. The graphite layer and the metal core are bonded by mechanical and glue. Because graphite slabs have the characteristics of heat resistance, pressure resistance and corrosion resistance under extreme conditions, they are widely used in the automotive, refining and petrochemical industries.Tanged Graphite Sheet is a homogeneous material that contains no adhesives or binders. Even after long service periods, this material displays no notable change in its properties compared with other sealing materials. Inhibitors can be added to enhance oxidation and corrosion resistance properties of the flexible graphite if required. The two sides of the Tanged Graphite Sheet are pure expanded graphite plates with a metal core thickness of 0.1 mm and a stainless steel material of SS316L. The graphite layer and the metal core are bonded by mechanical and glue. Because graphite slabs have the characteristics of heat resistance, pressure resistance and corrosion resistance under extreme conditions, they are widely used in the automotive, refining and petrochemical industries.
Tanged Graphite Sheet Application:
1. Suitable for steam systems
2. Widely used in in chemical and petrochemical industries, processing industries
3. Making gaskets of cylinders for are compressors, internal combustion engines
4. Packing for different kinds of piping, and flanges
Tanged Graphite Sheet Specification:
上方是模板内容,下方是编辑器原内容,编辑好请删除原内容.
Description:
Graphite sheet with metal foil 440P is made of expanded flexible graphite 440, reinforced by a smooth stainless steel-carrier of 1.4301 (304) or 1.4401 (316), Nickel, 0.05mm thick, graphite content of more then 98 %, graphite bulk density 1.0 g/cm3. Normal Style: 440P/304, 440P/316,440P/Other metal foil material
Application:
"Graphite sheet with metal foil made for various gaskets.
Graphite sheet with metal foil suitable for Petrochemical, Mining, Vessels, Boilers, Piping and Duct, Pumps and Valves, Flanges,"
Parameter:
"Temperature: -200 up to 550°C
Pressure: up to 400 bar
PH Range: 0 - 14"
Benefit:
Permanently elastic, even in hot-cold cycles over the entire temperature range, no aging, no brittleness, no hot or cold flow, long time uniform compressibility and resiliency independent of temperature.
Media:
Steam, mineral oils, heat transfer oils, hydraulic oil, fuel, water, seawater, freshwater etc.
Dimension:
"1000 x 1000 x1.0 ; 1.5 ; 2.0 ; 3.0mm
1000 x 2000 x1.0 ; 1.5 ; 2.0 ; 3.0mm
1500 x 1500 x1.0 ; 1.5 ; 2.0 ; 3.0mm
1500 x 2000 x1.0 ; 1.5 ; 2.0 ; 3.0mm
"
1. What is your MOQ?
MOQ may vary by customer's special requirement; we try our best to meet your business requirement.
2. What's your payment terms?
We normally do T/T, and we can also offer western union account for transfer money. And more flexible payment terms, welcome to have a discuss.
3. Can you provide samples?
Yes, we can offer samples, and some samples are free
4. Can you delivery by express?
Yes, we can delivery by any express.
5. When will the sample be ready?
Normally, the sample can be ready in 3 days.
Hot Tags: graphite sheet with metal foil, China, manufacturers, supplier, factory, wholesale, bulk, in stock, made in China
