The Bottom Discharge Valve is made of stainless steel 304 and 316, which has excellent chemical resistance and corrosion resistance. Bottom Discharge Valve consists of valve body, main valve disc, main valve disc sealing ring, positioning spring, spring positioning mechanism, main valve disc top opening mechanism, valve plate, valve seat, valve seat sealing ring, valve plate switch mechanism, limit wrench , end cover, protective cover and protective cover gasket and other parts. When loading, the combined discharge valve of the tank container is closed. When unloading, first remove the protective cover, then open the valve plate, and finally open the main valve disc to discharge the material in the tank container through the main valve disc top opening mechanism.
|
Specification: |
|
|
Design Pressure |
4bar |
|
Testing Pressure |
6bar |
|
Design Temperature |
-40-205℃ |
|
Valve Body Material |
304/316 |
|
Weight |
8.65KG |
|
Inlet |
flange connection |
|
Selective |
3" BSP connection |
For more details, please click here.
